Super junction MOSFETs
原廠：美格納半導體 (Magnachip)
MOSFET 500V / 600V / 650V / 700V / 800V / 900V
MOSFET 500V / 600V / 650V / 700V / 800V / 900V
Super junction MOSFETs
500V
Product
Vds [V]
Ids [A] 25°C
Vgs(th) [Max V]
Rds(on) [mOhm Max] at Vgs=10V
Qg[nC]
Option
Package
Datasheet
Max
Typ
MMF50R280PTH
500
13.0
4.0
280
250
28.6
TO-220F
MMD50R380PRH
500
11.0
3.5
380
350
21.8
DPAK
* R2FET: Rapid Recovery MOSFET, TO-220FS: Trim Lead, IPAK-SL: Short Lead, IPAK-VSL: Very Short Lead
C-Ver.: Vgs(th)=Max 4.0V, G-Ver.: High Rg, B-Ver.: High Rg + Vgs(th)=Max 4.0V
| Product | Vds [V] | Ids [A] 25°C | Vgs(th) [Max V] | Rds(on) [mOhm Max] at Vgs=10V | Qg[nC] | Option | Package | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|
| Max | Typ | ||||||||
| MMF50R280PTH | 500 | 13.0 | 4.0 | 280 | 250 | 28.6 | TO-220F |
|
|
| MMD50R380PRH | 500 | 11.0 | 3.5 | 380 | 350 | 21.8 | DPAK |
|
|
|
* R2FET: Rapid Recovery MOSFET, TO-220FS: Trim Lead, IPAK-SL: Short Lead, IPAK-VSL: Very Short Lead C-Ver.: Vgs(th)=Max 4.0V, G-Ver.: High Rg, B-Ver.: High Rg + Vgs(th)=Max 4.0V |
|
||||||||
600V
Product
Vds [V]
Ids [A] 25°C
Vgs(th) [Max V]
Rds(on) [mOhm Max] at Vgs=10V
Qg[nC]
Option
Package
Datasheet
Max
Typ
MMQ60R044RFTH
600
60.0
5.0
44
38
154.0
TO-247
MMQ60R070PTH
600
53.0
4.0
70
63
132.0
TO-247
MMQ60R078RFTH
600
50.0
5.0
78
66
88.0
TO-247
MMQ60R115PTH
600
33.0
4.0
115
104
79.0
TO-247
MMFT60R115PCTH
600
33.0
4.0
115
104
77.0
TO-220FT
MMQ60R115PCTH
600
33.0
4.0
115
104
77.0
TO-247
MMF60R115PTH
600
33.0
4.0
115
104
79.0
TO-220F
MMSF60R190RTH
600
20.0
4.0
190
170
36.1
TO-220SF
MMF60R190RTH
600
20.0
4.0
190
170
36.1
TO-220F
MMSF60R190QTH
600
20.0
4.0
190
170
36.0
TO-220SF
MMF60R190PTH
600
20.0
4.0
190
170
51.0
TO-220F
MMP60R190PTH
600
20.0
4.0
190
170
51.0
TO-220
MMQ60R190PTH
600
20.0
4.0
190
170
51.0
TO-247
MMF60R190QTH
600
20.0
4.0
190
170
36.0
TO-220F
MMFT60R190QTH
600
20.0
4.0
195
170
36.0
TO-220FT
MMP60R195PCTH
600
20.0
4.0
195
175
44.0
TO-220
MMFT60R195PCTH
600
20.0
4.0
195
175
44.0
TO-220FT
MMSF60R280RZTH
600
13.8
4.0
280
250
24.7
TO-220SF
MMF60R280RZTH
600
13.8
4.0
280
250
24.7
TO-220F
MMD60R280RZRH
600
13.8
4.0
280
250
24.7
TO-252
MMSF60R280QTH
600
13.8
4.0
280
250
18.3
TO-220SF
MMF60R280QTH
600
13.8
4.0
280
250
18.3
TO-220F
MMF60R290PTH
600
13.0
4.0
290
260
33.0
TO-220F
MMP60R290PTH
600
13.0
4.0
290
260
32.0
TO-220
MME60R290PRH
600
13.0
4.0
290
260
32.0
D2PAK
MMFT60R290PCTH
600
13.0
4.0
290
260
32.0
TO-220FT
MME60R290QRH
600
13.8
4.0
290
250
25.0
D2PAK
MMFT60R280QTH
600
13.8
4.0
293
250
25.0
TO-220FT
MMD60R300QRH
600
13.8
4.0
300
270
25.0
DPAK
MMSF60R360RZTH
600
11.0
4.0
360
320
19.4
TO-220SF
MMF60R360RZTH
600
11.0
4.0
360
320
19.4
TO-220F
MMD60R360RZRH
600
11.0
4.0
360
320
19.4
TO-252
MMD60R360QRH
600
11.0
4.0
360
320
19.0
DPAK
MMSF60R360QTH
600
11.0
4.0
360
320
19.0
TO-220SF
MMP60R360PTH
600
11.0
4.0
360
320
28.0
TO-220
MMD60R360PRH
600
11.0
4.0
360
350
28.0
DPAK
MMF60R360QTH
600
11.0
4.0
360
320
19.0
TO-220F
MMF60R360PTH
600
11.0
4.0
360
320
28.0
TO-220F
MMFT60R380PCTH
600
11.0
4.0
380
350
25.0
TO-220FT
MMD60R400RFZRH
600
11.0
5.0
403
360
18.4
TO-252
MMFA60R400RFZTH
600
11.0
5.0
403
360
18.4
TO-220FA
MMSF60R580RZTH
600
8.0
4.0
580
510
12.8
TO-220SF
MMF60R580RZTH
600
8.0
4.0
580
510
12.8
TO-220F
MMD60R580RZRH
600
8.0
4.0
580
510
12.8
TO-252
MMD60R580QRH
600
8.0
4.0
580
530
13.0
DPAK
MMSF60R580QTH
600
8.0
4.0
580
530
13.0
TO-220SF
MMF60R580PTH
600
8.0
4.0
580
530
18.0
TO-220F
MMD60R580PRH
600
8.0
4.0
580
530
18.0
DPAK
MMIS60R580PTH
600
8.0
4.0
580
530
18.0
VS IPAK
MMF60R580QTH
600
8.0
4.0
580
530
13.0
TO-220F
MMHS60R650RFZURH
600
8.0
5.0
650
590
13.0
SOT-223-2L
MMD60R650RFZRH
600
8.0
5.0
650
590
13.0
TO-252
MMFA60R650RFZTH
600
8.0
5.0
650
590
13.0
TO-220FA
MMF60R750PTH
600
5.7
4.0
750
680
14.0
TO-220F
MMD60R750PRH
600
5.7
4.0
750
680
14.0
DPAK
MMIS60R750PTH
600
5.7
4.0
750
680
15.0
VS IPAK
MMD60R900QRH
600
4.4
4.0
900
760
9.6
DPAK
MMD60R900PRH
600
4.5
4.0
900
810
12.3
DPAK
MMIS60R900PTH
600
4.5
4.0
900
810
12.3
VS IPAK
MMFA60R1K0RFZTH
600
3.0
5.0
1010
910
7.2
TO-220FA
MMD60R1K0RFZRH
600
3.0
5.0
1010
910
7.2
TO-252
600V
| Product | Vds [V] | Ids [A] 25°C | Vgs(th) [Max V] | Rds(on) [mOhm Max] at Vgs=10V | Qg[nC] | Option | Package | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|
| Max | Typ | ||||||||
| MMQ60R044RFTH | 600 | 60.0 | 5.0 | 44 | 38 | 154.0 | TO-247 |
|
|
| MMQ60R070PTH | 600 | 53.0 | 4.0 | 70 | 63 | 132.0 | TO-247 |
|
|
| MMQ60R078RFTH | 600 | 50.0 | 5.0 | 78 | 66 | 88.0 | TO-247 |
|
|
| MMQ60R115PTH | 600 | 33.0 | 4.0 | 115 | 104 | 79.0 | TO-247 |
|
|
| MMFT60R115PCTH | 600 | 33.0 | 4.0 | 115 | 104 | 77.0 | TO-220FT |
|
|
| MMQ60R115PCTH | 600 | 33.0 | 4.0 | 115 | 104 | 77.0 | TO-247 |
|
|
| MMF60R115PTH | 600 | 33.0 | 4.0 | 115 | 104 | 79.0 | TO-220F |
|
|
| MMSF60R190RTH | 600 | 20.0 | 4.0 | 190 | 170 | 36.1 | TO-220SF |
|
|
| MMF60R190RTH | 600 | 20.0 | 4.0 | 190 | 170 | 36.1 | TO-220F |
|
|
| MMSF60R190QTH | 600 | 20.0 | 4.0 | 190 | 170 | 36.0 | TO-220SF |
|
|
| MMF60R190PTH | 600 | 20.0 | 4.0 | 190 | 170 | 51.0 | TO-220F |
|
|
| MMP60R190PTH | 600 | 20.0 | 4.0 | 190 | 170 | 51.0 | TO-220 |
|
|
| MMQ60R190PTH | 600 | 20.0 | 4.0 | 190 | 170 | 51.0 | TO-247 |
|
|
| MMF60R190QTH | 600 | 20.0 | 4.0 | 190 | 170 | 36.0 | TO-220F |
|
|
| MMFT60R190QTH | 600 | 20.0 | 4.0 | 195 | 170 | 36.0 | TO-220FT |
|
|
| MMP60R195PCTH | 600 | 20.0 | 4.0 | 195 | 175 | 44.0 | TO-220 |
|
|
| MMFT60R195PCTH | 600 | 20.0 | 4.0 | 195 | 175 | 44.0 | TO-220FT |
|
|
| MMSF60R280RZTH | 600 | 13.8 | 4.0 | 280 | 250 | 24.7 | TO-220SF |
|
|
| MMF60R280RZTH | 600 | 13.8 | 4.0 | 280 | 250 | 24.7 | TO-220F |
|
|
| MMD60R280RZRH | 600 | 13.8 | 4.0 | 280 | 250 | 24.7 | TO-252 |
|
|
| MMSF60R280QTH | 600 | 13.8 | 4.0 | 280 | 250 | 18.3 | TO-220SF |
|
|
| MMF60R280QTH | 600 | 13.8 | 4.0 | 280 | 250 | 18.3 | TO-220F |
|
|
| MMF60R290PTH | 600 | 13.0 | 4.0 | 290 | 260 | 33.0 | TO-220F |
|
|
| MMP60R290PTH | 600 | 13.0 | 4.0 | 290 | 260 | 32.0 | TO-220 |
|
|
| MME60R290PRH | 600 | 13.0 | 4.0 | 290 | 260 | 32.0 | D2PAK |
|
|
| MMFT60R290PCTH | 600 | 13.0 | 4.0 | 290 | 260 | 32.0 | TO-220FT |
|
|
| MME60R290QRH | 600 | 13.8 | 4.0 | 290 | 250 | 25.0 | D2PAK |
|
|
| MMFT60R280QTH | 600 | 13.8 | 4.0 | 293 | 250 | 25.0 | TO-220FT |
|
|
| MMD60R300QRH | 600 | 13.8 | 4.0 | 300 | 270 | 25.0 | DPAK |
|
|
| MMSF60R360RZTH | 600 | 11.0 | 4.0 | 360 | 320 | 19.4 | TO-220SF |
|
|
| MMF60R360RZTH | 600 | 11.0 | 4.0 | 360 | 320 | 19.4 | TO-220F |
|
|
| MMD60R360RZRH | 600 | 11.0 | 4.0 | 360 | 320 | 19.4 | TO-252 |
|
|
| MMD60R360QRH | 600 | 11.0 | 4.0 | 360 | 320 | 19.0 | DPAK |
|
|
| MMSF60R360QTH | 600 | 11.0 | 4.0 | 360 | 320 | 19.0 | TO-220SF |
|
|
| MMP60R360PTH | 600 | 11.0 | 4.0 | 360 | 320 | 28.0 | TO-220 |
|
|
| MMD60R360PRH | 600 | 11.0 | 4.0 | 360 | 350 | 28.0 | DPAK |
|
|
| MMF60R360QTH | 600 | 11.0 | 4.0 | 360 | 320 | 19.0 | TO-220F |
|
|
| MMF60R360PTH | 600 | 11.0 | 4.0 | 360 | 320 | 28.0 | TO-220F |
|
|
| MMFT60R380PCTH | 600 | 11.0 | 4.0 | 380 | 350 | 25.0 | TO-220FT |
|
|
| MMD60R400RFZRH | 600 | 11.0 | 5.0 | 403 | 360 | 18.4 | TO-252 |
|
|
| MMFA60R400RFZTH | 600 | 11.0 | 5.0 | 403 | 360 | 18.4 | TO-220FA |
|
|
| MMSF60R580RZTH | 600 | 8.0 | 4.0 | 580 | 510 | 12.8 | TO-220SF |
|
|
| MMF60R580RZTH | 600 | 8.0 | 4.0 | 580 | 510 | 12.8 | TO-220F |
|
|
| MMD60R580RZRH | 600 | 8.0 | 4.0 | 580 | 510 | 12.8 | TO-252 |
|
|
| MMD60R580QRH | 600 | 8.0 | 4.0 | 580 | 530 | 13.0 | DPAK |
|
|
| MMSF60R580QTH | 600 | 8.0 | 4.0 | 580 | 530 | 13.0 | TO-220SF |
|
|
| MMF60R580PTH | 600 | 8.0 | 4.0 | 580 | 530 | 18.0 | TO-220F |
|
|
| MMD60R580PRH | 600 | 8.0 | 4.0 | 580 | 530 | 18.0 | DPAK |
|
|
| MMIS60R580PTH | 600 | 8.0 | 4.0 | 580 | 530 | 18.0 | VS IPAK |
|
|
| MMF60R580QTH | 600 | 8.0 | 4.0 | 580 | 530 | 13.0 | TO-220F |
|
|
| MMHS60R650RFZURH | 600 | 8.0 | 5.0 | 650 | 590 | 13.0 | SOT-223-2L |
|
|
| MMD60R650RFZRH | 600 | 8.0 | 5.0 | 650 | 590 | 13.0 | TO-252 |
|
|
| MMFA60R650RFZTH | 600 | 8.0 | 5.0 | 650 | 590 | 13.0 | TO-220FA |
|
|
| MMF60R750PTH | 600 | 5.7 | 4.0 | 750 | 680 | 14.0 | TO-220F |
|
|
| MMD60R750PRH | 600 | 5.7 | 4.0 | 750 | 680 | 14.0 | DPAK |
|
|
| MMIS60R750PTH | 600 | 5.7 | 4.0 | 750 | 680 | 15.0 | VS IPAK |
|
|
| MMD60R900QRH | 600 | 4.4 | 4.0 | 900 | 760 | 9.6 | DPAK |
|
|
| MMD60R900PRH | 600 | 4.5 | 4.0 | 900 | 810 | 12.3 | DPAK |
|
|
| MMIS60R900PTH | 600 | 4.5 | 4.0 | 900 | 810 | 12.3 | VS IPAK |
|
|
| MMFA60R1K0RFZTH | 600 | 3.0 | 5.0 | 1010 | 910 | 7.2 | TO-220FA |
|
|
| MMD60R1K0RFZRH | 600 | 3.0 | 5.0 | 1010 | 910 | 7.2 | TO-252 |
|
|
650V
| Product | Vds [V] | Ids [A] 25°C | Vgs(th) [Max V] | Rds(on) [mOhm Max] at Vgs=10V | Qg[nC] | Option | Package | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|
| Max | Typ | ||||||||
| MMFT65R380QTH | 650 | 11.0 | 4.0 | 380 | 340 | 20.6 | TO-220FT |
|
|
| MMF65R190PTH | 650 | 20.0 | 4.0 | 190 | 170 | 53.0 | TO-220F |
|
|
| MMP65R190PTH | 650 | 20.0 | 4.0 | 190 | 170 | 53.0 | TO-220 |
|
|
| MMFT65R195PTH | 650 | 20.0 | 4.0 | 195 | 175 | 53.0 | TO-220FT |
|
|
| MME65R280QRH | 650 | 13.8 | 4.0 | 280 | 240 | 27.8 | D2PAK |
|
|
| MMD65R380QRH | 650 | 10.6 | 4.0 | 380 | 340 | 20.6 | DPAK |
|
|
| MMD65R600QRH | 650 | 7.3 | 4.0 | 600 | 540 | 13.8 | DPAK |
|
|
| MMD65R900QRH | 650 | 4.7 | 4.0 | 900 | 800 | 11.1 | DPAK |
|
|
| MMF65R600QTH | 650 | 7.3 | 4.0 | 600 | 540 | 13.8 | TO-220F |
|
|
| MMF65R380QTH | 650 | 10.6 | 4.0 | 380 | 340 | 20.6 | TO-220F |
|
|
| MMP65R380QTH | 650 | 10.6 | 4.0 | 380 | 340 | 20.6 | TO-220 |
|
|
700V
| Product | Vds [V] | Ids [A] 25°C | Vgs(th) [Max V] | Rds(on) [mOhm Max] at Vgs=10V | Qg[nC] | Option | Package | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|
| Max | Typ | ||||||||
| MMF70R600QTH | 700 | 7.3 | 4.0 | 600 | 540 | 15.0 | TO-220F |
|
|
| MMD70R900QRH | 700 | 5.0 | 4.0 | 900 | 810 | 11.0 | DPAK |
|
|
| MMD70R600QRH | 700 | 7.3 | 4.0 | 600 | 540 | 15.0 | DPAK |
|
|
| MMF70R900QTH | 700 | 5.0 | 4.0 | 900 | 810 | 11.0 | TO-220F |
|
|
| MMF70R900PTH | 700 | 5.0 | 4.0 | 900 | 810 | 15.0 | TO-220F |
|
|
| MMD70R900PRH | 700 | 5.0 | 4.0 | 900 | 810 | 15.0 | DPAK |
|
|
| MMIS70R900PTH | 700 | 5.0 | 4.0 | 900 | 810 | 15.0 | VS IPAK |
|
|
| MMD70R1K4PRH | 700 | 3.2 | 4.0 | 1400 | 1260 | 11.0 | DPAK |
|
|
| MMIS70R1K4PTH | 700 | 3.2 | 4.0 | 1400 | 1260 | 11.0 | VS IPAK |
|
|
| MMFT70R380PTH | 700 | 11.0 | 4.0 | 380 | 340 | 34.0 | TO-220FT |
|
|
| MMD70R600PRH | 700 | 7.3 | 4.0 | 600 | 540 | 23.0 | DPAK |
|
|
| MME70R380PRH | 700 | 11.0 | 4.0 | 380 | 340 | 34.0 | D2PAK |
|
|
| MMF70R600PTH | 700 | 7.3 | 4.0 | 600 | 540 | 23.0 | TO-220F |
|
|
| MMHS70R1K4PRH | 700 | 3.2 | 4.0 | 1400 | 1260 | 11.0 | SOT-223-2L |
|
|
| MMHS70R1K6QURH | 700 | 5.4 | 4.0 | 1600 | 1410 | 6.1 | SOT-223-2L |
|
|
800V
| Product | Vds [V] | Ids [A] 25°C | Vgs(th) [Max V] | Rds(on) [mOhm Max] at Vgs=10V | Qg[nC] | Option | Package | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|
| Max | Typ | ||||||||
| MME80R290RRH | 800 | 17.0 | 4.0 | 290 | 250 | 39.0 | D2PAK |
|
|
| MMF80R290RTH | 800 | 17.0 | 4.0 | 290 | 250 | 39.0 | TO-220F |
|
|
| MMF80R450PBTH | 800 | 11.0 | 4.0 | 450 | 390 | 37.6 | TO-220F |
|
|
| MMF80R900PTH | 800 | 6.0 | 4.0 | 900 | 780 | 17.6 | TO-220F |
|
|
| MMF80R450QZTH | 800 | 11.0 | 4.0 | 450 | 390 | 25.0 | TO-220F |
|
|
| MME80R290PRH | 800 | 17.0 | 4.0 | 290 | 250 | 56.0 | D2PAK |
|
|
| MMD80R900PCRH | 800 | 6.0 | 4.0 | 900 | 780 | 17.6 | DPAK |
|
|
| MMF80R900PCTH | 800 | 6.0 | 4.0 | 900 | 780 | 17.6 | TO-220F |
|
|
| MMD80R1K2PRH | 800 | 4.5 | 4.0 | 1200 | 950 | 15.2 | DPAK |
|
|
| MMP80R900PCTH | 800 | 6.0 | 4.0 | 900 | 780 | 17.6 | TO-220 |
|
|
| MMF80R1K2PTH | 800 | 4.5 | 4.0 | 1200 | 950 | 15.2 | TO-220F |
|
|
| MMD80R900QZRH | 800 | 6.0 | 4.0 | 900 | 780 | 13.0 | DPAK |
|
|
| MMF80R900QZTH | 800 | 6.0 | 4.0 | 900 | 780 | 13.0 | TO-220 |
|
|
| MMD80R1K2QZRH | 800 | 4.5 | 4.0 | 1200 | 950 | 11.0 | DPAK |
|
|
| MMF80R1K2QZTH | 800 | 6.0 | 4.0 | 1200 | 950 | 13.0 | TO-220F |
|
|
| MMF80R650QZTH | 800 | 8.0 | 4.0 | 650 | 560 | 18.0 | TO-220F |
|
|
| MMF80R450PTH | 800 | 11.0 | 4.0 | 450 | 390 | 37.6 | TO-220F |
|
|
| MMF80R650PTH | 800 | 8.0 | 4.0 | 650 | 560 | 25.8 | TO-220F |
|
|
900V
| Product | Vds [V] | Ids [A] 25°C | Vgs(th) [Max V] | Rds(on) [mOhm Max] at Vgs=10V | Qg[nC] | Option | Package | Datasheet | |
|---|---|---|---|---|---|---|---|---|---|
| Max | Typ | ||||||||
| MMIS90R1K4PTH-PE | 900 | 5.0 | 4.0 | 1490 | 1260 | 13.6 | IPAK-PE |
|
|
| MMD90R1K4PRH | 900 | 5.0 | 4.0 | 1490 | 1260 | 13.6 | DPAK |
|
|
